2021 Big Tex Trailer
Vin: 16V1U1717M4061426
Stock #: ETN53
Internet Price:
$4,125
Est. Monthly Payment:
$120
Year:
2021
Make:
Big Tex
Type/Model:
Trailer
Exterior Color:
BLACK
Stock #:
ETN53
VIN:
16V1U1717M4061426
2021 BIG TEX 35SA-14BKRSX WITH SIDE LOADER
35SA-RSX SINGLE AXLE ATV TRAILER
STANDARD FEATURES
DESCRIPTION
• (6) Tie Down Loops Inside Bed
• Set-Back Jack
• EZ Lube Hubs
• Dexter Brand Axle
• 2“ Square Tubing Top Rail
• Grommet-Mount Sealed Lighting
• L.E.D. Lighting Package
• Protected Wiring
• Front Spare Tire Mount
• Radial Tires
• Brake Flanges on Axle for Easy Brake Addition
• Removable Sand Foot on Jack
• A-Frame Channel Tongue
• Rear Tailboard Channels (Deleted if Rampgate
Added)
• (2) 5‘ Square Tubing ATV Ramp Sides
• Ramps Can be Used on Either Side and on Rear
Dimensions
Length A B C
12’ 145-1/2” 85” 60-1/2”
14’ 169-1/2” 97” 72-1/2”
G.V.W.R. 2,995# AXLE 3,500# EZ Lube Axle w/ Brake Flanges
G.A.W.R. (Ea. Axle) 3,500# SUSPENSION Multi-Leaf Spring
COUPLER 2" A-Frame TIRE ST205/75R-15 Load Range C
SAFETY CHAINS 1/4" Grd. 30 w/ Safety Latch Hook (2 ea) WHEEL 15" x 5; Black Mod, 5 on 5 Bolt Pattern
JACK 2,000# Top Wind, Set-Back Jack FLOOR 2" Treated Pine or Douglas Fir*
TONGUE 3" Channel LIGHTS L.E.D. D.O.T. Stop, Tail, Turn & Clearance
TOP RAIL 2" Square Tubing ELEC. PLUG 4-Way Flat w/ Loom
FRAME 4" x 3" x 1/4" Angle FINISH (Prep) Steel is Cleaned to Ensure a
CROSSMEMBERS 3" x 2" x 3/16" Angle Professional, Smooth Finish
UPRIGHTS 14" Tall Angle, 2" x 2" x 1/8" Angle FINISH Superior Quality Finish is Applied for a
FENDERS 9" x 32" Rolled Formed w/ Back Highly Decorative and Protective Finish
Big Tex Trailer Manufacturing, LLC warrants that each Big Tex trailer operated by the original purchaser under normal use in the Continental United States or Canada will be free from defects in materials and workmanship for one (1) year following the original purchase, subject to the requirements.
The structure of your Big Tex trailer is warranted to the original retail purchaser against defects in materials and workmanship by Big Tex Trailer Manufacturing, LLC, arising from normal use for three (3) years from the date of purchase.The structure is that portion of the trailer which includes the main frame, consisting of the bottom rails, cross members, and the sub frame, excluding the floorboards (where applicable) and running gear.
Big Tex Trailer Manufacturing, LLC warrants its paint finish to be consistent with industry standards for 90 days from the date of original retail purchase, with the exceptions of “normal use”
Lumber is warranted for 90 days from the date of original retail purchase.
For complete warranty information please see your owners manual or visit bigtex.
35SA-RSX SINGLE AXLE ATV TRAILER
STANDARD FEATURES
DESCRIPTION
• (6) Tie Down Loops Inside Bed
• Set-Back Jack
• EZ Lube Hubs
• Dexter Brand Axle
• 2“ Square Tubing Top Rail
• Grommet-Mount Sealed Lighting
• L.E.D. Lighting Package
• Protected Wiring
• Front Spare Tire Mount
• Radial Tires
• Brake Flanges on Axle for Easy Brake Addition
• Removable Sand Foot on Jack
• A-Frame Channel Tongue
• Rear Tailboard Channels (Deleted if Rampgate
Added)
• (2) 5‘ Square Tubing ATV Ramp Sides
• Ramps Can be Used on Either Side and on Rear
Dimensions
Length A B C
12’ 145-1/2” 85” 60-1/2”
14’ 169-1/2” 97” 72-1/2”
G.V.W.R. 2,995# AXLE 3,500# EZ Lube Axle w/ Brake Flanges
G.A.W.R. (Ea. Axle) 3,500# SUSPENSION Multi-Leaf Spring
COUPLER 2" A-Frame TIRE ST205/75R-15 Load Range C
SAFETY CHAINS 1/4" Grd. 30 w/ Safety Latch Hook (2 ea) WHEEL 15" x 5; Black Mod, 5 on 5 Bolt Pattern
JACK 2,000# Top Wind, Set-Back Jack FLOOR 2" Treated Pine or Douglas Fir*
TONGUE 3" Channel LIGHTS L.E.D. D.O.T. Stop, Tail, Turn & Clearance
TOP RAIL 2" Square Tubing ELEC. PLUG 4-Way Flat w/ Loom
FRAME 4" x 3" x 1/4" Angle FINISH (Prep) Steel is Cleaned to Ensure a
CROSSMEMBERS 3" x 2" x 3/16" Angle Professional, Smooth Finish
UPRIGHTS 14" Tall Angle, 2" x 2" x 1/8" Angle FINISH Superior Quality Finish is Applied for a
FENDERS 9" x 32" Rolled Formed w/ Back Highly Decorative and Protective Finish
Big Tex Trailer Manufacturing, LLC warrants that each Big Tex trailer operated by the original purchaser under normal use in the Continental United States or Canada will be free from defects in materials and workmanship for one (1) year following the original purchase, subject to the requirements.
The structure of your Big Tex trailer is warranted to the original retail purchaser against defects in materials and workmanship by Big Tex Trailer Manufacturing, LLC, arising from normal use for three (3) years from the date of purchase.The structure is that portion of the trailer which includes the main frame, consisting of the bottom rails, cross members, and the sub frame, excluding the floorboards (where applicable) and running gear.
Big Tex Trailer Manufacturing, LLC warrants its paint finish to be consistent with industry standards for 90 days from the date of original retail purchase, with the exceptions of “normal use”
Lumber is warranted for 90 days from the date of original retail purchase.
For complete warranty information please see your owners manual or visit bigtex.
Vehicle Comments
2021 BIG TEX 35SA-14BKRSX WITH SIDE LOADER
35SA-RSX SINGLE AXLE ATV TRAILER
STANDARD FEATURES
DESCRIPTION
• (6) Tie Down Loops Inside Bed
• Set-Back Jack
• EZ Lube Hubs
• Dexter Brand Axle
• 2“ Square Tubing Top Rail
• Grommet-Mount Sealed Lighting
• L.E.D. Lighting Package
• Protected Wiring
• Front Spare Tire Mount
• Radial Tires
• Brake Flanges on Axle for Easy Brake Addition
• Removable Sand Foot on Jack
• A-Frame Channel Tongue
• Rear Tailboard Channels (Deleted if Rampgate
Added)
• (2) 5‘ Square Tubing ATV Ramp Sides
• Ramps Can be Used on Either Side and on Rear
Dimensions
Length A B C
12’ 145-1/2” 85” 60-1/2”
14’ 169-1/2” 97” 72-1/2”
G.V.W.R. 2,995# AXLE 3,500# EZ Lube Axle w/ Brake Flanges
G.A.W.R. (Ea. Axle) 3,500# SUSPENSION Multi-Leaf Spring
COUPLER 2" A-Frame TIRE ST205/75R-15 Load Range C
SAFETY CHAINS 1/4" Grd. 30 w/ Safety Latch Hook (2 ea) WHEEL 15" x 5; Black Mod, 5 on 5 Bolt Pattern
JACK 2,000# Top Wind, Set-Back Jack FLOOR 2" Treated Pine or Douglas Fir*
TONGUE 3" Channel LIGHTS L.E.D. D.O.T. Stop, Tail, Turn & Clearance
TOP RAIL 2" Square Tubing ELEC. PLUG 4-Way Flat w/ Loom
FRAME 4" x 3" x 1/4" Angle FINISH (Prep) Steel is Cleaned to Ensure a
CROSSMEMBERS 3" x 2" x 3/16" Angle Professional, Smooth Finish
UPRIGHTS 14" Tall Angle, 2" x 2" x 1/8" Angle FINISH Superior Quality Finish is Applied for a
FENDERS 9" x 32" Rolled Formed w/ Back Highly Decorative and Protective Finish
Big Tex Trailer Manufacturing, LLC warrants that each Big Tex trailer operated by the original purchaser under normal use in the Continental United States or Canada will be free from defects in materials and workmanship for one (1) year following the original purchase, subject to the requirements.
The structure of your Big Tex trailer is warranted to the original retail purchaser against defects in materials and workmanship by Big Tex Trailer Manufacturing, LLC, arising from normal use for three (3) years from the date of purchase.The structure is that portion of the trailer which includes the main frame, consisting of the bottom rails, cross members, and the sub frame, excluding the floorboards (where applicable) and running gear.
Big Tex Trailer Manufacturing, LLC warrants its paint finish to be consistent with industry standards for 90 days from the date of original retail purchase, with the exceptions of “normal use”
Lumber is warranted for 90 days from the date of original retail purchase.
For complete warranty information please see your owners manual or visit bigtex.
35SA-RSX SINGLE AXLE ATV TRAILER
STANDARD FEATURES
DESCRIPTION
• (6) Tie Down Loops Inside Bed
• Set-Back Jack
• EZ Lube Hubs
• Dexter Brand Axle
• 2“ Square Tubing Top Rail
• Grommet-Mount Sealed Lighting
• L.E.D. Lighting Package
• Protected Wiring
• Front Spare Tire Mount
• Radial Tires
• Brake Flanges on Axle for Easy Brake Addition
• Removable Sand Foot on Jack
• A-Frame Channel Tongue
• Rear Tailboard Channels (Deleted if Rampgate
Added)
• (2) 5‘ Square Tubing ATV Ramp Sides
• Ramps Can be Used on Either Side and on Rear
Dimensions
Length A B C
12’ 145-1/2” 85” 60-1/2”
14’ 169-1/2” 97” 72-1/2”
G.V.W.R. 2,995# AXLE 3,500# EZ Lube Axle w/ Brake Flanges
G.A.W.R. (Ea. Axle) 3,500# SUSPENSION Multi-Leaf Spring
COUPLER 2" A-Frame TIRE ST205/75R-15 Load Range C
SAFETY CHAINS 1/4" Grd. 30 w/ Safety Latch Hook (2 ea) WHEEL 15" x 5; Black Mod, 5 on 5 Bolt Pattern
JACK 2,000# Top Wind, Set-Back Jack FLOOR 2" Treated Pine or Douglas Fir*
TONGUE 3" Channel LIGHTS L.E.D. D.O.T. Stop, Tail, Turn & Clearance
TOP RAIL 2" Square Tubing ELEC. PLUG 4-Way Flat w/ Loom
FRAME 4" x 3" x 1/4" Angle FINISH (Prep) Steel is Cleaned to Ensure a
CROSSMEMBERS 3" x 2" x 3/16" Angle Professional, Smooth Finish
UPRIGHTS 14" Tall Angle, 2" x 2" x 1/8" Angle FINISH Superior Quality Finish is Applied for a
FENDERS 9" x 32" Rolled Formed w/ Back Highly Decorative and Protective Finish
Big Tex Trailer Manufacturing, LLC warrants that each Big Tex trailer operated by the original purchaser under normal use in the Continental United States or Canada will be free from defects in materials and workmanship for one (1) year following the original purchase, subject to the requirements.
The structure of your Big Tex trailer is warranted to the original retail purchaser against defects in materials and workmanship by Big Tex Trailer Manufacturing, LLC, arising from normal use for three (3) years from the date of purchase.The structure is that portion of the trailer which includes the main frame, consisting of the bottom rails, cross members, and the sub frame, excluding the floorboards (where applicable) and running gear.
Big Tex Trailer Manufacturing, LLC warrants its paint finish to be consistent with industry standards for 90 days from the date of original retail purchase, with the exceptions of “normal use”
Lumber is warranted for 90 days from the date of original retail purchase.
For complete warranty information please see your owners manual or visit bigtex.
