14TL HEAVY DUTY TILT BED EQUIPMENT -22FT
G.V.W.R. 14,000# AXLE (2) 7,000#, 4” Drop EZ Lube w/Electric
Brakes
G.A.W.R. (Ea. Axle) 7,000# SUSPENSION Multi-Leaf Slipper Spring w/Equalizer
COUPLER Adjustable 2-5/16” 18,000# Demco EZ
Latch
TIRE ST235/80 R-16 Load Range E
SAFETY CHAINS 3/8” Grd. 70 w/Safety Latch Hook (2 ea) WHEEL 16" x 6"; Black Mod, 8 Bolt
JACK 12,000# Drop Leg Jack-Side Wind FLOOR 2" Treated Pine or Douglas Fir*
TONGUE/NECK 6” Channel Fold Back/Wrap Tongue LIGHTS L.E.D. D.O.T. Stop, Tail, Turn & Clearance
10" I-Beam Neck on GN ELEC. PLUG 7-Way RV
FRONT STOP RAIL 3/16" Fabricated Front Stop Rail FINISH (Prep) Steel is Cleaned to Ensure a Professional
FRAME 6” Channel Smooth Finish.
CROSSMEMBERS 3” Channel on 16” Centers FINISH Superior Quality Finish is Applied for a
FENDERS 9” x 72” 14 Ga. Diamond Plate Double Highly Decorative and Protective Finish.
Square Broke w/Back (Removable)
* Douglas Fir Available from Caldwell, ID Facility Only
• Rubrail and Stake Pockets Along Sides
• (6) D-Rings to Secure Equipment
• Adjustable 2-5/16” Demco EZ Latch Coupler
• Fold Back/Wrap Tongue w/ Raised Coupler
• 12,000# Drop Leg Jack- Side Wind
• *Dual Jacks & Front Toolbox on Gooseneck Model
• Fabricated Front Stop Rail
• EZ Lube Hubs
• Dexter Brand Axles
• Nev-R-Adjust Electric Brakes on All Hubs
• Cambered 4” Drop Axles
• Complete Break-A-Way System w/Charger
• Zip™ Breakaway Cable
• 14 Ga. Double Square Broke Diamond Plate Fenders
(Removable)
• Single-Side, EZ Pedal Locking Mechanism
• Stationary Front Deck for Added Versatility
• Unique Two Piece Main Frame
• Full 83“ Wide Bed Between Fenders
• Tilt Platform is 75” Wide
• Hydraulic Dampening Cylinder w/ Valve Control
• 1/4” Diamond Plate Knife Edge on Rear
• Grommet Mount Sealed Lighting
• L.E.D. Lighting Package
• Sealed Modular Wiring Harness
• Spare Tire Mount (Front)
• Radial Tires
• 102” Wide Overall, 83” Width Between Fenders
• Tilt Platform is 75” Wide
• Hydraulic Dampening System
• Reflective
